induction-motor-DKM 8IDGE-25G-T-8GBK10BMH
| Motor Model | Output | Voltage V |
Freq Hz |
Starting Torque | Rated Torque | Rated Current A |
Rated Speed r/min |
Duty Min |
Certificate | TP | ||||
| kgfcm | N.m | oz-in | kgfcm | N.m | oz-in | |||||||||
| 8IDGE-25G-T | 25 | 220 | 50 | 1.57 | 0.157 | 1.95 | 0.195 | 0.23 | 1250 | Cont. | CE | O | ||
| 240 | 50 | 1.87 | 0.187 | 1.95 | 0.195 | 0.25 | 1250 | |||||||
| Gearhead Model | Ratio | Speed RPM | Permissible Torque | 최대허용토크/허용 Overhung 하중과 허용 Thrust 하중표 | Certificate | ||||||||
| 50Hz | 60Hz | 50Hz | 60Hz | 최대허용토크 | 허용 Overhung 하중 | 허용 Thrust 하중 | |||||||
| RPM | RPM | Kg·m | N·m | Ib·in | Kg·m | N·m | Ib·in | kgfcm | kg | kg | |||
| 8GBK10BMH | 10.00 | 150 | 180 | 14.6 | 1.43 | 12.3 | 1.21 | 25.00 | 12.00 | 5 | |||
