| Motor Model | Output | Voltage V |
Freq Hz |
Starting Torque | Rated Torque | Rated Current A |
Rated Speed r/min |
Duty Min |
Certificate | TP | ||||
| kgfcm | N.m | oz-in | kgfcm | N.m | oz-in | |||||||||
| 9IDDK-200F-AT | 200 | 380 | 50 | 17.57 | 1.757 | 7.49 | 0.749 | 0.55 | 2600 | Cont. | O | |||
| 60 | 13.91 | 1.391 | 6.09 | 0.609 | 0.48 | 3200 | ||||||||
| 400 | 50 | 19.15 | 1.915 | 7.49 | 0.749 | 0.55 | 2600 | |||||||
| 60 | 15.27 | 1.527 | 6.09 | 0.609 | 0.49 | 3200 | ||||||||
