induction-motor-DKM 9IDGE-180FH-T-9HBK10BH
| Motor Model | Output | Voltage V |
Freq Hz |
Starting Torque | Rated Torque | Rated Current A |
Rated Speed r/min |
Duty Min |
Certificate | TP | ||||
| kgfcm | N.m | oz-in | kgfcm | N.m | oz-in | |||||||||
| 9IDGE-180FH-T | 180 | 220 | 50 | 8.10 | 0.810 | 14.03 | 1.403 | 1.50 | 1250 | Cont. | CE | O | ||
| 240 | 50 | 9.70 | 0.970 | 13.49 | 1.349 | 1.60 | 1250 | |||||||
| Gearhead Model | Ratio | Speed RPM | Permissible Torque | 최대허용토크/허용 Overhung 하중과 허용 Thrust 하중표 | Certificate | ||||||||
| 50Hz | 60Hz | 50Hz | 60Hz | 최대허용토크 | 허용 Overhung 하중 | 허용 Thrust 하중 | |||||||
| RPM | RPM | Kg·m | N·m | Ib·in | Kg·m | N·m | Ib·in | kgfcm | kg | kg | |||
| 9HBK10BH | 10.00 | 150 | 180 | 109.2 | 10.71 | 88.8 | 8.70 | 300.00 | 55.00 | 15 | |||
